Guide for wall mounted wave rails

First, identify if there are any radiators, window sills, or other elements protruding from the wall.

Starting from the left or right, mark the first hole:

– 6cm from the side wall

– Use a 5cm, 10cm or 15cm wall depending on the deepest protuding point (e.g. radiator or sill).

Space the following holes 65–70cm apart for stable support.

• For double rails, please use a wall bracket adopted for double layers (20cm bracket).

Use a suitable drill or hammer drill and drill holes at the marked points.

Insert an appropriate wall plug into every drilled hole, based on wall material.

Use a screwdriver or drill to secure the wall brackets with suitable screws. The rail should be attached directly to the wall.

If using multiple rails, join them together using the provided connectors.

Click the rail into the mounted brackets securely.

Your custom-made french curtain from GARDINEX comes pre-installed with hooks. No need to add or adjust them before hanging. The curtain is designed to be hung on a loose glider system.

If you are using a GARDINEX french-compatible rail, the loose gliders are already pre-installed in the correct configuration – no extra setup needed.

The number of gliders must match the number of hooks on the curtain. If you're using a rail with not purchased from us, ensure that:

- The rail is compatible with wave systems.

- It contains loose gliders. The gliders match the number and of hooks on your curtain.

Place curtain weights in the side pockets of each curtains for a heavier fall.
